Advanced Titanium Alloy Globe Valve (Stop Valve)
The Titanium Alloy Globe Valve is the definitive solution for reliable fluid control in systems involving harsh, oxidizing, or corrosive media, such as seawater, chlorides, and select industrial chemicals. Its inherent material properties and specialized sealing structure ensure maximum service life and integrity in applications where common stainless steel or alloy valves fail.
🔬 Section I: Titanium’s Corrosion Superiority
Unlike general materials, Titanium exists in a passive state across many aggressive media, exhibiting an electrode potential similar to passive 18-8 Stainless Steel. This passivation layer provides exceptional resistance to chemical attack.
| Electrochemical Behavior (In Seawater) | Detail | Engineering Implication |
| Passive Potential | Titanium’s potential is low (-0.10V vs. Saturated Calomel Electrode). | Minimal risk of Galvanic Corrosion when in contact with Monel, Hastelloy C, 18-8 SS, and Nickel-added Aluminum Bronze. |
| Active Protection | When coupled with Aluminum, Zinc, or Carbon Steel, Titanium accelerates the corrosion of these less noble metals. | Design Consideration: The ratio of the surface area of the contacting metal to Titanium is critical. A ratio of 1:10 (Anode:Cathode) rapidly corrodes the contacted metal; a 10:1 ratio significantly reduces the corrosion rate. |
🛠️ Section II: Specialized Structure and Sealing
The Titanium Alloy Globe Valve is designed for superior shutoff and long-term sealing performance:
- Sealing Structure: Employs a Flat Sealing Structure.
- Sealing Surface Material: The critical seating surfaces on the Disc and Body are fabricated directly from high-strength Titanium Alloy Ti 60.
- Importance of Ti 60: This material choice provides the necessary characteristics for reliable seating, including:
- Excellent anti-galling properties.
- Superior corrosion resistance and thermal stability.
- Suitable hardness to maintain seal integrity under pressure.
This combination is vital for preventing fluid leaks (internal or external) which could cause environmental pollution, economic loss, or catastrophic failure with toxic, corrosive, or flammable fluids.
🏭 Section III: Main Parts Material Options
| Component Name | Titanium Alloy Option | Common Stainless Steel/Carbon Steel Options |
| Body / Bonnet | Titanium (Specialized Alloys) | ZG1Cr18Ni9Ti, ZG00Cr18Ni10, ZG1Cr18Ni12Mo 2 Ti, WCB |
| Disc | Titanium (Specialized Alloys) | ZG1Cr18Ni9Ti, ZG00Cr18Ni10, ZG1Cr18Ni12Mo 2 Ti, 1Cr13 |
| Stem | Titanium (Specialized Alloys) | 00Cr18Ni10, 1Cr18Ni12Mo 2 Ti, 1Cr13 |
| Packing | PTFE Braided | Graphite |
This valve is an ideal choice for shutoff applications in highly aggressive fluids.
