Stainless Steel 3-Way Flanged Plug Valve

The Stainless Steel 3-Way Flanged Plug Valve is a specialized quarter-turn valve designed for flow diversion, mixing, or isolation in multi-port piping systems. The stainless steel construction (typically SS304 or SS316/CF8M) makes it ideal for handling corrosive fluids, food-grade media, and high-purity applications, while the flanged ends ensure a robust and reliable connection to the pipeline.

Core Functionality and Design

A 3-Way Plug Valve uses a cylindrical or tapered plug with a flow path drilled through it. By rotating the plug $90$ degrees (quarter-turn), the operator can change the flow direction between three distinct ports.

Flow Configuration: The internal porting can typically be configured in two main styles:
- L-Port: Directs flow from the common inlet to one of the two outlets, or vice-versa. It cannot connect all three ports simultaneously.
- T-Port: Can direct flow between any two ports, or in some designs, connect all three ports together for mixing or distribution.
Plug Type: These valves are often of the Sleeved (non-lubricated PTFE/Teflon sleeve) or Lubricated design, with non-lubricated being common for stainless steel chemical and sanitary applications.
Full Port Option: Many designs feature a $100\%$ port area for low head loss and the ability to pass large solids, particularly beneficial in slurry or wastewater diversion (though stainless steel is more commonly used for clean, corrosive fluids).

Key Features of Stainless Steel & Flanged Design

Feature	Detail & Benefit
Material	Stainless Steel (SS304 / SS316 or Cast CF8 / CF8M). Provides superior resistance to corrosion, high temperatures, and chemical attack, making it suitable for acids, solvents, and sanitary processes.
Connection	Flanged Ends (e.g., ASME B16.5 Class 150/300, DIN PN16/PN40). Ensures a robust, leak-tight, and highly secure connection essential for chemical and high-pressure lines.
Operation	Quarter-turn operation allows for quick and easy switching between flow paths.
Low Maintenance	Simple design with few moving parts, especially in the non-lubricated type. Sleeved versions allow for in-line maintenance/adjustment in some designs.
Versatility	Simplifies piping networks by replacing two separate isolation valves and several fittings, saving space and cost.

Typical Specifications

Parameter	Standard Specifications
Material Grades	Stainless Steel (SS304, SS316, CF8, CF8M, CF3M)
Size Range	NPS $1/2''$ to $24''$ (DN15 to DN600)
Pressure Ratings	ASME Class 150, 300, 600 Lbs, or PN16, PN40
Applicable Standards	API 599, API 6D, ASME B16.10, ASME B16.5
End Connections	Flanged (Raised Face – RF or Flat Face – FF)

Common Applications

The Stainless Steel 3-Way Flanged Plug Valve is primarily used for directional control in high-purity and corrosive environments:

Chemical and Petrochemical: Diverting or mixing various corrosive streams.
Pharmaceutical and Food & Beverage: Sanitary applications requiring SS316L and clean-in-place (CIP) compatibility.
Oil and Gas: Directional flow control in piping manifolds and process lines.
Power Industry: Switching fluid paths in non-steam systems.
